Dream Star
Different Angle:
Feature:
| SPECIFICATIONS : |
XT110-9 |
| CONFIGURE : |
|
| Colors available : |
* |
| Features : |
* |
| Decals (Y/N) : |
Y |
| Sundries box(Y/N) : |
N |
| Remote start (Y/N) : |
N |
| Remote engine stop (Y/N) : |
N |
| Remote alarm (Y/N) : |
N |
| Speed limiter (Y/N) : |
N |
| Assembly required : |
Rearview mirror,battery,handle bar,front wheel,front fender,front cover ,
feet rest,muffle |
| ENGINE INFO : |
|
| Engine type : |
4-stroke,single cylinder |
| Engine brand : |
* |
| Displacement : |
108ml |
| Cooling : |
Air-cooled |
| Max horsepowe : |
6.8hp/8000r/min |
| Max torque : |
6.8n.m/6000r/min |
| Bore*stroke : |
2.1*1.97inch |
| Max speed : |
47mile/h |
| Climbing ability : |
15degree |
| Ignition : |
C.D.I |
| Starting system : |
Electric/kick |
| Battery : |
12V/5Ah |
| Carburetor brand : |
PZ19 |
| Engine oil : |
SAE15W/40 SF |
| Gear oil : |
|
| CHASSIS ETC : |
|
| Clutch : |
automatic clutch |
| Transmission : |
4-speed |
| Driveline : |
chain |
| Driving wheel : |
Rear wheel drive |
| Suspension,front/rear : |
hydraulic damper/double spring |
| Brakes,front/rear : |
Disc/drum |
| Brake operation : |
Hand/Foot |
| Tires,front/rear : |
2.50-17/2.75-17 |
| Fuel capacity/type : |
1.4gal |
| Weight,G.W./N.W : |
303/250lbs |
| Max load : |
330lbs |
| DIMENSIONS : |
|
| Wheelbase : |
48.8inch |
| OA L*W*H : |
77.8*28.3*42.96inch |
| Height to seat : |
29.5inch |
| Min ground clearance : |
5.9inch |
| Carton size : |
66.9*18*33inch |
| Shipping info : |
105/40HQ | |
